TECHNICAL SPECIFICATIONS
| CPU | Supports 10th Gen Intel Core™ and Pentium Gold / Celeron processors for LGA1200 socket |
| Chipset | Intel B460 Chipset |
| Memory | 2x DDR4 memory slots, support up to 64GB Intel Core™ i7/ i9 - Supports up to DDR4 2933 MHz Intel Core™ i5 and below - Supports up to DDR4 2666 MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel Extreme Memory Profile (XMP) |
| Expansion Slots | 1x PCIe 3.0 x16 slot 2x PCIe 3.0 x1 slots |
| Onboard Graphics | 1x DVI-D port, supports a maximum resolution of 1920x1200 @60Hz 1x HDMI™ 1.4 port, supports a maximum resolution of 4096x2160 @30Hz Maximum shared memory is 1GB |
| Storage | Intel B460 Chipset 6x SATA 6Gb/s ports 1x M.2 slot (Key M) - Supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280 storage devices - Intel Optane™ Memory Ready* - Supports Intel Smart Response Technology for Intel Core™ processors SATA2 will be unavailable when installing M.2 SATA SSD in the M.2 slot. Before using Intel Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website. |
| RAID | Intel B460 Chipset Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA storage devices |
| USB | Intel B460 Chipset 6x USB 3.2 Gen 1 5Gbps ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 3.2 Gen 1 5Gbps connector) 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors) |
| Audio | Realtek ALC892 Codec 7.1-Channel High Definition Audio |
| LAN | 1x Realtek 8111H Gigabit LAN controller |
| Internal Connectors | 1x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 6x SATA 6Gb/s connectors 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x USB 3.2 Gen1 5Gbps connector (supports additional 2 USB 3.2 Gen1 5Gbps ports) 1x 4-pin CPU fan connector 1x 4-pin system fan connector 1x Front panel audio connector 2x Front panel connectors 1x TPM module connector 1x Serial port connector 1x Chassis Intrusion connector 1x Clear CMOS jumper 4x EZ Debug LED |
| Back Panel Ports | USB 2.0 Type-A ports LAN port PS/2 keyboard/ mouse combo port DVI-D port HDMI port USB 3.2 Gen1 5Gbps Type-A ports USB 3.2 Gen1 5Gbps Type-A ports Audio jacks |
| Form Factor | mATX Form Factor 9.3 in. x 7.6 in. (23.6 cm x 19.2 cm) |
| BIOS Features | 1x 128 Mb flash UEFI AMI BIOS Multi-language |
