ELITE NEX 230V

The Elite NEX White power supply unit is a dependable choice for entry level users and system integrators. The quiet 120mm fan, Active PFC, and 3 years warranty deliver a PSU that provides function you can count on. This power supply unit has been engineered for reliability. The Elite NEX is a complete solution, offering performance and stability at an affordable price.

Active pfc + dual forward topology design

: Constructed with protective measures normally found in high-end power supplies to increase safety and current stability.

High temperature resistance

: Capable of operating at 40°C under full load allowing a longer lifespan in warmer environments.

Peak power tolerance

: Can reliably push an additional 100W at peak power load for up to 20 seconds.

80 plus white eu 230v efficiency

: Maintains a higher efficiency of 85% at typical load.

Durable, reliable, and safe

: Will perform consistently in whatever environment whether it\'s high altitudes or ultra humid settings.

3 year warranty

: This unit comes with a standard limited manufacturing warranty of 3 years from the date of purchase.

TECHNICAL SPECIFICATIONS

ATX Version
ATX12V Rev. 2.41

PFC
Active PFC

Input Voltage
200 - 240V

Input Current
5A

Input Frequency
50 - 60Hz

Dimension (L x W x H)
140 x 150 x 86mm

Fan Size
120mm

Fan Bearing
Sleeve Fan

Efficiency
>= 85% @ Typical Load

ERP 2014 LOT 3
Yes

Operating Temperature
0 - 40°C

Power Good Signal
100 - 500 ms

Hold Up Time
>= 10ms at 100% Load

MTBF
>100,000 hours

Protections
OVP / OPP / SCP / UVP / OTP / Inrush Protection

Regulatory
TUV,cTUVus,CE,FCC,CCC,EAC,UKCA

ATX 24-pin Connnectors
x1 = 1x (550mm)

EPS 4+4 Pin & EPS 8Pin
x2 = 1x [550(8Pin)+120(4+4Pin)mm]

SATA Connectors
x2 = 1x (400+150mm); x3 = 1x (400+150+150mm)

Peripheral 4-pin Connectors
x3 = 1x (400+150+150mm)

PCI-E 6+2 pin Connectors
x2 = 1x (500+120mm)
