Hardware Specifications
CPU Dual-core, 1.00GHz, Cortex A53 RAM / FLASH 1GB / 256MB 10/100/1000 Mbps RJ-45 ports 1 x WAN: 1 GbE RJ45 port 4 x LAN: 1 GbE RJ45 ports System Capacity & Performance SPI firewall throughput LAN to WAN (Mbps) 890 Throughput with threat Management on (Mbps) 880 Wireless Specifications Standard compliance IEEE 802.11ax 6 GHz IEEE 802.11 ax /ac/n/a 5 GHz IEEE 802.11 ax /n/b/g 2.4 GHz Wireless frequency 2.4 / 5 /6 GHz Radio 3 SSID number 4 No. of antenna 4(internal) Antenna gain 2.0 dBi @ 2.4 GHz 3.0 dBi @ 5 GHz 3.5 dBi @ 6 GHz* Wireless speed 6 GHz: 2402 Mbps 5 GHz: 2402 Mbps 2.4 GHz: 574 Mbps Key Features Security Features Ransomware / malware protection Yes Intrusion blocker Yes Dark Web Blocker Yes Stop mail fraud & phishing Yes Block Ads Yes Block VPN proxy Yes Web Filtering Yes Firewall Yes Country Restriction (GeoIP) Yes Allowlist / Blocklist Yes Traffic Management (applications & clients) Yes Real-time threat intelligence1 Yes Web Filtering (DNS)1 Yes Nebula Pro Pack*1 Yes VPN Features Site-to-site VPN IPSec Networking WAN type Static IP, DHCP, PPPoE, and PPPoE with Static IP Networking Features Port forwarding Guest VLAN DHCP IP/MAC binding MAC filter Network Address Translation (NAT) & port forwarding Yes DHCP server / client and DHCP relay Yes Dynamic DNS Yes Network Address Translation (NAT) & port forwarding Yes Static route Yes IGMP Proxy Yes WLAN Management Firmware upgrade Yes Configuration backup and restore Yes Live tools Yes Power Requirements Power input 12V DC, 2.0 A Max. power consumption (Watt Max.) 21W Physical Specifications Item Dimensions (WxDxH)(mm/in.) 178.0 X 54.6 (stand 68.2) X 242.2 mm Weight (g/lb.) 651g (with stand) Environmental Specifications
Operating
Temperature
0oC to 40oC
Humidity
10% to 90% (non-condensing)
Storage
Temperature
-30oC to 70oC
Humidity
10% to 95% (non-Condensing)
Certifications
CE
FCC
BSMI
