Aruba Instant On 1430 8G Class4 PoE 64W Switch (R8R46A) | |
I/O ports and slots | 8 RJ-45 autosensing 10/100/1000 Class 4 PoE ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only |
Dimensions | 150(d) x 177(w) x 37(h) mm |
Weight | 1.70 lb (0.77 kg) |
Processor and Memory | 128Kb EEPROM; Packet buffer size: 2.0 Mb |
Performance | |
100 Mb latency | < 2.7 µSec |
1000 Mb latency | < 1.80 µSec |
Throughput (Mpps) | 11.90 Mpps |
Capacity | 16 Gbps |
MAC address table size | 8192 entries |
Reliability MTBF (years) | 131.1 |
Operating temperature | 32°F to 104°F (0°C to 40°C) |
Operating relative humidity | 15% to 95% @ 104°F (40°C) non-condensing |
Nonoperating/ storage temperature | -40°F to 158°F (-40°C to 70°C) up to 15000 ft |
Nonoperating/ storage relative humidity | 15% to 90% @ 149°F (65°C) non-condensing |
Altitude | up to 10,000 ft (3 km) |
Acoustics | Fanless |
Frequency | 50Hz/60Hz |
AC voltage | 100-240VAC |
Current | 2A (54VDC - 1.58A) |
Maximum power rating | 90W |
Idle power | 4.1W |
PoE power | 64W Class 4 PoE |
Power Supply | External Power Adapter |
Safety | EN/IEC 60950- 1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 EN/IEC 62368-1, 2nd. & 3rd. Ed. UL 62368-1, 3rd. Ed. CAN/CSA C22.2 No. 62368-1, 3rd. Ed. EN/IEC 60825- 1:2014 Class 1 |
Emissions | EN 55032:2015/ CISPR 32, Class B FCC CFR 47 Part 15: 2018, Class B ICES-003, Class B VCCI-32, Class B CNS 13438, Class B KS C 9832, Class B AS/NZS CISPR 32, Class B |
Immunity | BS/EN 55035, CISPR 35, KS C 9835 |
Generic | EN 55035, CISPR 35 |
EN | EN/IEC 61000-4-2 |
ESD | EN/IEC 61000-4-3 |
Radiated | EN/IEC 61000-4-4 |
EFT/Burst | EN/IEC 61000-4-5 |
Surge | EN/IEC 61000-4-6 |
Conducted | EN/IEC 61000-4-8 |
Power frequency magnetic field | EN/IEC 61000-4-11 |
Voltage dips and interruptions | EN/IEC 61000-3- 2 |
Harmonics | EN /IEC 61000-3-3 |
Device Management | Unmanaged |
Mounting positions and supported racking | Mounts in an EIA standard 19 in telco rack or equipment cabinet. 2-post rack kit included Supports table-top mounting Supports rack-mounting using the brackets provided Supports wall-mounting with ports facing either up or down using either the base surface mounting holes, or the brackets provided Supports under-table mounting using the brackets provided Must be mounted top surface up. To prevent possible impact to long-term reliability, product should not be mounted upside-down |
