WIRELESS
Standards and Protocols Wi-Fi 6

• IEEE 802.11a/n/ac/ax 5 GHz
• IEEE 802.11b/g/n/ac/ax 2.4 GHz

WiFi Speeds AX3000

5 GHz: 2402 Mbps (802.11ax) 2.4 GHz: 574 Mbps (802.11ax)

WiFi Capacity High Dual-Band

• Allocate devices to different bands for optimal performance
• Airtime Fairness

Improves network efficiency by limiting excessive occupation 4 Streams Connect your devices to more bandwidth

Working Modes Router Mode

USB Tethering Mode 3G/4G USB Modem Mode

• Hotspot Mode (WISP Mode)
• Access Point Mode
• Range Extender Mode
• Client Mode

SECURITY
Network Security SPI Firewall

• Access Control
• IP & MAC Binding

Application Layer Gateway

Guest Network 1× 5 GHz Guest Network

1× 2.4 GHz Guest Network

VPN Server • OpenVPN Server

• PPTP VPN Server • L2TP VPN Server • Wireguard VPN Serve

VPN Client Open VPN Client

• PPTP VPN Client • L2TP VPN Client • Wireguard VPN Client

WiFi Encryption WPA2-PSK

• WPA3-Personal
• WPA/WPA2-Enterprise

HARDWARE
Ethernet Ports 2.5× Gigabit WAN Port

1× Gigabit LAN Port

USB Support 1× USB 3.0 Port
Buttons WPS/Reset Button

ECO Switch

Power 5V/3A,External DC power adapter
SOFTWARE FEATURES
Quality of Service QoS by Device
WAN Type Dynamic IP

• Static IP
• PPPoE
• PPTP
• L2TP

Management Features Tether App

Webpage

DHCP DHCP Server

• DHCP Client List
• Address Reservation

Protocols IPv4

IPv6

OTHER
Network Services Enabled by Default Web Server

Manage and configure device through web (HTTP/HTTPS) • Port: 80/443 Protocol: TCP

• DNS
• DNS

• Port: 53 Protocol: TCP & UDP

• DHCP Server
• IP address assignment (DHCP)

• Port: 67 Protocol: UDP

• App management
• Manage and configure device through app

• Port: 20001 Protocol: TCP • Port: 30001 Protocol: TCP • Port: 20002 Protocol: UDP

Certifications FCC, CE
Environment Operating Temperature: 0?~40? (32? ~104?)

• Storage Temperature: -40?~60? (-40? ~140?)
• Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

TEST DATA
WiFi Transmission Power CE:
