EAP215-Bridge KIT
Vnútorný/vonkajší prístupový bod Omada Wireless Bridge 5 GHz 867 Mb/s
802.11ac pre až 867 Mbps pri rýchlosti bezdrôtového prenosu na 5 GHz.1
Ideálne pre dlhodobý bezdrôtový prenos až do 5 km.2
Automatické párovanie a flexibilné LED diódy pre efektívne nasadenie.
3× Gigabit Ethernetové porty pre viac pripojení vysokorýchlostných IP kamier.6
Podpora Omada SDN pre vzdialený a centralizovaný manažment.
Odolná IP65 krytie proti počasiu a ochrana proti blesku 6kV zaisťujú vhodnosť pre všetky poveternostné podmienky.3
Podpora Passive PoE pre flexibilné nasadenie (adaptér je súčasťou balenia).
HARDWARE FEATURES
Interface 3x Gigabit Ethernet Ports6
Button Reset
Power Supply 12V DC / 24V Passive PoE (Passive PoE adapter included.)
Power Consumption 11.5W
Dimensions ( W x D x H ) 3.1 x 2.4 x 8.8 in (79 × 60 × 224 mm)
Antenna Type Internal 2×2 Dual-polarized directional MIMO antennas
5 GHz: 11.0 dBi
Horizontal:35°, Vertical: 35°
Weatherproof Enclosure IP65
Mounting Pole mounting (Accessories included)
WIRELESS FEATURES
Coverage 5000m(16400ft)5
Wireless Standards IEEE 802.11 a/b/g/n/ac
Frequency 5 GHz
Signal Rate 5 GHz: Up to 867 Mbps
Wireless Functions • Mesh4
• MU-MIMO: 5G 2x2 MU-MIMO DL
• Load Balance
• Beamforming
• Seamless Roaming(802.11r)
• Airtime Fairness
• Multiple SSIDs:8
• Wireless Statistics
• Wireless Schedule
• Reboot Schedule
• RADIUS Accounting
• MAC Authentication
• Static IP/Dynamic IP
Wireless Security • VLAN
• Access Control
• Rogue AP Detection
• Captive Portal Authentication*4
• Maximum number of MAC Filter: 4,000
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise
Transmission Power • CE:
• FCC:
MANAGEMENT
Omada App Yes
Restore & Backup Yes
Firmware update via Web Yes
NTP Yes
Centralized Management • Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
• Omada Cloud-Based Controller
Cloud Access Yes. Require the use of OC300, OC200, the Omada Software Controller, or Omada Cloud-Based Controller.
LED ON/OFF Control Yes
Management MAC Access Control Yes
SNMP v1, v2c, v3
SSH Yes
Web-based Management Yes
OTHERS
Certification CE, FCC, RoHS
Package Contents • EAP215-Bridge KIT
• Passive PoE Adapter
• Power Cord
• Installation Guide
• Mounting Kit
Environment • Operating Temperature: -40 °C-70 °C (-40 °F-158 °F);
• Storage Temperature: -40 °C-70 °C (-40 °F-158 °F);
• Operating Humidity: 10%-90% non-condensing;
• Storage Humidity: 5%-90% non-condensing
